0448002000-vvs

Filter ball valve 480

by Impel EN AB
Material: Nickel-plated brass. Working Temperature: -20ºC/+100ºC. Max Working Pressure: 16 bar.
ArtnrConnectionLength mmWeight kgDescriptionKv (m3/h)
0448002000
3/4"F650,54Filter ball valve 480-20, 3/4"F, lever7,1
0448002500
1"F780,81Filter ball valve 480-25, 1"F, lever12,6
0448003200
1 1/4"F871,28Filter ball valve 480-32, 1 1/4"F, lever24,7
0448004000
1 1/2"F1082,02Filter ball valve 480-40, 1 1/2"F, lever36,8
0448005000
2"F1273,77Filter ball valve 480-50, 2"F, lever62,7
Product Sheet Operation & Maintenance Mounting
